Society of Manchester, illustrating my paper with many drawings. But as my paper was of considerable length, and as the illustrations would prove costly to engrave, it was not published in the Society's Transactions. They are still, however, kept in the library for reference by those who take a special interest in the subject.

A Mode of transmitting Rotary Motion by means of a Flexible Shaft, formed of a Coiled Spiral Wire or Rod of Steel.

While assisting Mr. Maudslay in the execution of a special piece of machinery, in which it became necessary to have some holes drilled in rather inaccessible portions of the work in hand, and where the employment of the ordinary drill was impossible, it occurred to me that a flexible shaft, formed of a closely coiled spiral of steel wire, might enable us to transmit the requisite rotary motion to a drill attached to the end of this spiral shaft. Mr. Maudslay was much pleased with the notion, and I speedily put it in action by a close coiled spiral wire of about two feet in length.

This was found to transmit the requisite rotary motion to the drill at the end of the spiral with perfect and faithful efficiency. The difficulty was got over, to Mr. Maudslay's great satisfaction.

So far as I am aware, such a mode of transmitting rotary motion was new and original. The device was useful, and proved of essential service in other important applications. By a suitably close coiled spiral steel wire I have conveyed rotary motion quite round an obstacle, such as is indicated in the annexed figure.

It has acted with perfect faithfulness from the winch handle at A to the drill at B. Any ingenious mechanic will be able to appreciate the value of such a flexible shaft in many applications . Four years ago I saw the same arrangement in action at a dentist's operating-room, when a drill was worked in the mouth of a patient to enable a decayed tooth to be stopped. It was said to be the last thing out in "Yankee notions." It was merely a replica of my flexible drill of 1829.

A Machine for cutting the Key-Grooves in Metal Wheels and Belt Pulleys, of ANY Diameter.

The fastening of wheels and belt pulleys to shafts, so as to enable them to transmit rotary motion, is one of the most frequently-recurring processes in the construction of machinery. This is best effected by driving a slightly tapered iron or steel wedge, or "key" as it is technically termed, into a corresponding recess, or flat part of the shaft, so that the wheel and shaft thus become in effect one solid structure.

The old mode of cutting such key-grooves in the eyes of wheels was accomplished by the laborious and costly process of chipping and filing. Maudslay's mortising machine, which he contrived for the Block machinery, although intended originally to operate upon wood, contained all the essential principles and details required for acting on metals. Mr. Richard Roberts, by some excellent modifications, enabled it to mortise or cut out the key-grooves in metal wheels, and this method soon came into general use. This machine consisted of a vertical slide bar, to the lower end of which was attached the steel mortising tool, which received its requisite up and down motion from an adjustable crank, through a suitable arrangement of the gearing. The wheel to be operated upon was fixed to a slide-table, and gradually advanced, so as to cause the mortising tool to take successive cuts through the depth of the eye of the wheel, until the mortise or key-groove had attained its required depth.

The only drawback to this admirable machine was that its service was limited in respect to admitting wheels whose half diameter did not exceed the distance from the back of the jaw of the machine to the face of the mortise tool; so that to give to this machine the requisite rigidity and strength to resist the strain on the jaw, due to the mortising of the key-grooves, in wheels of say 6 feet diameter, a more massive and cumbrous frame work was required, which was most costly in space as well as in money.
